Terminal Management System (TMS)
The Terminal Management System integrates IPTV and other media content management, offering equipment management and user operation data support for operators, suppliers, and distributors, while also delivering precise content recommendations to end users.
How It Works
Our Android TV Box Terminal Management System (TMS) allows seamless monitoring, control, and management of multiple Android TV boxes across various locations through a centralized web-based interface. The system operates by connecting all components over the Internet, enabling real-time communication between users, servers, and TV boxes.
Users Access the Web-Based Interface
Multiple users, such as User 1 and User 2, can access the system through their web browsers. This interface allows them to view device statuses, manage content, monitor reports, and generate insights on the performance of the Android TV boxes deployed in the field.
Server & Database Communication
The server hosts the backend of the management system and is connected to a central database where all information, including device data and user activity, is stored. The server serves as the communication bridge between users and the TV boxes, ensuring that any changes or instructions initiated by users are delivered accurately to the respective boxes.
TV Boxes Managed via Internet
The system supports both local (intranet) and remote (internet) management of Android TV boxes. These boxes can be scattered across different locations and are grouped into clusters for efficient monitoring. The system communicates with the boxes to gather reports, send updates, and maintain a heartbeat connection to check the boxes’ health status.
Real-Time Reports & Heartbeats
Each Android TV box regularly sends status reports and heartbeats to the server, ensuring that the system remains up-to-date with the current operational state of each box. The heartbeat mechanism helps track device uptime, performance, and any potential issues, allowing administrators to address problems proactively.
Android TV Box Terminal Management System TMS Functions
Efficiently manage your Android TV Box fleet with our Terminal Management System (TMS).
Lock/Unlock Device
Remotely secure or grant access to the device.
Push Notification
Send instant notifications to devices.
OTA URL Change
Update the Over-The-Air (OTA) update URL for firmware.
Market URL Change
Modify the URL for app store or marketplace access.
Update APP Push Server URL
Change the server URL used for app push notifications.
Download Script and Execute
Fetch and run scripts directly on the device.
Download File to Specific Folder
Transfer files to a designated folder on the device.
Install/Uninstall APK to Box
Remotely add or remove APK files (applications).
Deploy RTC Schedule
Schedule tasks using the Real-Time Clock (RTC) feature.
Change NTP Server
Adjust the Network Time Protocol (NTP) server settings for accurate time synchronization.
Factory Reset
Restore the device to its original factory settings.
Reboot
Remotely restart the device.
Retrieve LOG
Collect and view system logs from the device for diagnostics.
IPTV/OTT Platform TVIP TMS
TMS (Terminal Management Service) is a cloud system used to remotely control deployed devices (terminals). It can perform functions such as lock/unlock, change configurations, push notifications, retrieve terminal status and statistics, and remote debugging.
Dashboard Interface
Device Management
Available CMD
Statistical Data
Alerts and Notifications
TMS Solution | TMS Software
Our TMS’s design is based on a terminal's heartbeat. Each time a terminal boots up, it will connect to the TMS server and report significant information, such as model, links, heartbeat intervals, and other details. It will then wait for a heartbeat interval to report an alive packet. TMS will determine if a device is online based on the heartbeat. If a terminal fails to report two consecutive heartbeat packets, TMS will flag this device as offline.
TMS uses 300 seconds as the heartbeat interval; only an admin can change this value. The value is determined by the number of terminals deployed and the TMS server’s capacity.
User Scenarios
Oranth TMS offers a highly adaptable solution for managing Android TV boxes across various industries. From hospitality and education to retail and healthcare, the TMS ensures that large-scale deployments of TV boxes are easy to manage, monitor, and update, providing businesses with operational efficiency and better user experiences.
Hospitality Industry
Managing TV boxes in hotel rooms.
Education Sector
Using TV boxes in classrooms or lecture halls.
Retail and Advertising
Digital signage in retail stores.
Corporate Environment
Managing meeting room displays.
Healthcare Facilities
TV boxes in patient rooms or waiting areas.
Transport Hubs
Deployment in airports or bus terminals.
Residential Complexes
Centralized control in apartment complexes.
Public Venues
Deployments in stadiums or event centers.
Why Choose the Oranth Android TV Box TMS?
Efficiency
How it saves time and resources by simplifying management tasks.
Cost-Effectiveness
Reduction in operational costs due to streamlined management.
Boost performance
Ensuring devices are always up-to-date and running optimally.
Enhanced Security
Protects against vulnerabilities and unauthorized access.
Frequently Asked Question (FAQ)
The Oranth Android TV Box terminal management system is compatible with our entire Tanix series and various development boards.
The minimum order quantity for customized devices using our Android TV Box system is 1,000 units.
Our terminal management system currently supports all devices running Android 10 and above.
For pricing details, please reach out to us directly. Our project managers will provide tailored solutions and quotes based on your requirements.
Yes, the system can connect to devices from other brands; however, it requires the installation of our firmware for compatibility.
The Oranth TMS employs robust security measures, including access controls, data encryption, and regular security audits, to ensure the protection of your data. We adhere to industry best practices and comply with relevant data protection regulations.
Yes, the Oranth TMS offers a high degree of customization. Our team works closely with you to understand your requirements and tailors the system accordingly, including UI/UX design, firmware customization, and integration with your existing infrastructure.
The Oranth TMS employs robust security measures, including access controls, data encryption, and regular security audits, to ensure the protection of your data. We adhere to industry best practices and comply with relevant data protection regulations.
The Oranth TMS is designed with user-friendliness in mind. Our intuitive interface and comprehensive documentation make it easy for your team to navigate and manage the system. We also provide training sessions to ensure smooth onboarding and effective utilization of the system’s features.
At Oranth, we are committed to providing excellent customer support. Our dedicated team of experts is available to assist you with any questions or issues you may encounter. We offer various support channels, including email, phone, and online ticketing systems, to ensure timely and efficient resolution of your concerns.
The Oranth TMS is designed to be highly scalable, allowing you to easily add more devices and users as your business grows. Our system architecture ensures seamless integration of new components, enabling you to expand your operations without compromising performance or functionality.
We understand the importance of system reliability for your business operations. The Oranth TMS is built on robust infrastructure and employs redundancy measures to minimize downtime. We strive to maintain a high uptime guarantee and work closely with you to ensure that your system operates at optimal levels consistently.
